Code

Model

Connections

Bar pressures

04101119

K-PF2ML/D5-4-COS

1/4”SAE

-1 +100 / 0 +160

Code

Model

Connections

Bar pressures

04022060

PF2ML/D5-4/K1

1/4”SAE

-1 +100 / 0 +160

W

E

L

D

I

N

G

C

O

N

D

E

N

S

A

T

I

O

N

T

O

O

L

S

-

V

A

L

V

E

S

C

O

N

S

U

M

A

B

L

E

S

W

A

T

E

R

P

U

M

P

S

F

I

T

T

I

N

G

S

I

N

S

T

R

U

M

E

N

T

S

Code

Model

Bar pressures

07113001

ML80/100R1/D5/K1

-1 +100

07113002

ML80/160R1/D5/K1

0 +160

Code

Model

Bar pressures

07113014

ML80/100C4S/D5/K1

-1 +100

07113015

ML80/160C4S/D5/K1

0 +160

R744

MANIFOLDS

CO

2

(R744) MANIFOLD KIT

2 ways piston manifold kit with Ø80 oil filled gauges for R744, class 1 with

regulation screw and stainless steel case, 3

flexible hoses in plastic case.

Code

Dimensions

Weight

04101119

360 x 320 x 120 mm

2,5 kg

CO

2

(R744) MANIFOLD

2 ways piston manifold with Ø80 oil

filled gauges for R744, class 1 with

regulation screw and stainless steel case.

Code

Dimensions

Weight

04022060

240 x 220 x 70 mm

0,9 kg

CO

2

(R744) GAUGES - RADIAL CONNECTION

Pressure guage, Ø 80, oil filled, class 1, radial connection 1/8NPT, with regulation

screw and and stainless steel case.

Code

07113001

07113002

Dimensions

100 x 90 x 40 mm

100 x 90 x 40 mm

Weight

0,3 kg

0,3 kg

CO

2

(R744) GAUGES - REAR CONNECTION

Pressure gauges, Ø 80, oil filled, class 1, rear connection 1/4 SAE, mounting

bracket and stainless stell case.

Code

07113014

07113015

Dimensions

90 x 90 x 70 mm

90 x 90 x 70 mm

Weight

0,3 kg

0,3 kg

97
