VACUUM - CHARGE

CERTIFIABLE SAMPLE PRESSURE GAUGE

DV-2 COOL/80

Certifiable sample pressure gauge for coolant examination

The DV-2 COOL was designed for monitoring tasks at coolant filling stations.

Vapour pressure/temperature values for 5 coolant liquids are saved in the unit and

can be selected by pressing a button.

The LCD switches from temperature to pressure at the touch of a button, with the

display offering a choice of bar/°C or PSI/°F.

The high resolution display means that DV-2 COOL can also be used for measuring

leaks in vacuums.

Coolant: the following coolants are stored in the gauge:

R134a - R404a - R507 - R407C liq. and vap. - R410A.

The battery symbol illuminates when battery power is low.

Pressure gauge DV-2 COOL can be supplied with Accredia report to be used as sam-

ple pressure gauge.

Code

Model

Description

07151004

DV-2 COOL/80

Certifiable sample pressure gauge

Code

Dimensions

07151004

125 x 95 x 40 mm

Technical features

Pressure ranges abs

Compensated range

Protection

Battery

Dimensions

Calibration

Weight

0,2 kg

0...80 bar

10...40 °C

IP 64

3V CR2032

68 x 70 x 35 mm

Accuracy

0,1 %FS

Storage/Operating Temperature

-10...60 °C / 0...50 °C

Connection

1/4” SAE

Battery life

2 months in continuous operation

Code

Description

09053008

Calibration report ref. Accredia for DV-2 COOL/80

74
