CO

2

(R744)

SCALE AND LEAK DETECTOR

R744

EXACTA-MAXI-C0

2

C0

2

(R744) electronic programmable scale

Very accurate charges, programmable by microprocessor.

Professional scale pan: 300 x 300 mm.

Code

Model

Dimensions

Weight

09013022 EXACTA-MAXI-CO2

460 x 350 x 170 mm

8,5 kg

Technical features

Capacity

Resolution

Accuracy

Scale pan dimensions

Operating temperature

Power supply

VOYAGER-R744

100 kg

± 2 gr up to 9.999 gr (capcity 30 kg)

± 10 gr (capacity 10 kg)

± 5 gr up to 30 kg

± 10 gr > 30 kg

300 x 300 mm

0 - 50 °C

230/1/50-60Hz

Infrared leak detector for CO

2

(R744)

VOYAGER- R744 is equipped with an infrared sensor specifically for CO

2

(R744) that

offers superior accuracy, insensitivity to false alarms and extended service life.

The robust construction with unique ergonomic design, the innovative large

LCD display and the rechargeable lithium-ion batteries make the infrared leak

detector not only extremely reliable, but also very intuitive and easy to use.

• 3 sensitivity levels (L/M/H).

• Audible alarm and optimised graphics on large LCD screen.

• High-quality, durable double-barrier probe.

• “Mute” button and connection for headphones.

• Peak storage function.

• Automatic calibration.

• Ergonomic grip.

• Sturdy case with battery charger and 5 spare tips with filters.

Code

Model

09001119 VOYAGER-R744

Technical features

Dimensions

Weight

INFRARED

330 x 240 x 70 mm

1,2 kg

Tecnology

Maximum sensitivity

Calibration

Warm-up time

Response time

Probe length

Power supply

Batteries life

Compliance

Infrared

<6 g/year

Automatic

<30 seconds

<3 seconds

40 cm

Rechargeagble lithium-ion battery

8 consecutive hours

CE, SAE J1627, EN14624

100
