66,5 (G1/2)

Rubinetteria

A5715AA

Valvola d’arresto

Neon

39 - 61 (G1/2)

43 - 65 (G3/4)

64

Built-in basin-mixer

Kit 2 - Design parts only

76,5 (G3/4)

CATALOGO PARTI DI RICAMBIO

A5715AA

chrome

M24x1

10

11

8

12

9

5

4

1

7

6

Pos. Description

1 Volume control handle

2 Handle cap

3 Cylindrcal screw M4x8

4 Thread pin M4x5 DIN914

5 Handle adapter

6 Sleeve

7 Escutcheon with rubber

8 Extension adapter

Part-

Number

A 962 947 AA

A 962 878 AA

A 860 738 NU

H 960 836 NU

A 963 673 AA

H 960 855 NU

Qty.

1 pcs

1 pcs

6 pcs

1 pcs

1 pcs

1 pcs

Pos. Description

9

Headwork for

Built-in valve G1/2

Headwork for

Built-in valve G3/4

10 Body built-in valve

11 Extension spindle

12 Extension kit

3

2

Part-

Number

A 961 761 NU

H 960 935 NU

A 860 464 NU

H 960 808 NU

Qty.

1 pcs

1 pcs

1 pcs

1 Set

Neon

pos.

Descrizione

Codici

1

Maniglia

A962947AA

2

Cappuccio maniglia

A962878AA

3

Vite M4x8

A860738NU

6

Manicotto

H960836NU

7

Rosone

A963673AA

pos. Descrizione

8

9

11

12

Codici

H960855NU

A961761NU

H960935NU

A860464NU

H960808NU

Adattatore

Cartuccia 1/2” destra

Parte superiore in ceramica 3/4” destra

Prolunga

Estensione valvola d’arresto da 1/2” e 3/4”
