Insulation and Protection of low voltage cable jonts and

terminations above and below ground.

The medium wall ensusres a good mechanical protection

Features and Bene ts

• Medium walled tubing with robust insulation characteristics

• Shrink tubing for above and underground cable applications

• Protects cable joints and terminations in low voltage

applications

• Coated inside with thermoplastic adhesive

• Protects against humidity and other environmental impacts

after shrinking

SHRINKABLE TUBING UP TO 4:1

G

UAINE

T

ERMORESTRINGENTI

Isolamento e protezione di giunzioni e terminazioni

di cavi elettrici a basso voltaggio sopra e sotto terra.

La parete media garantisce una buona protezione

meccanica

Caratteristiche del prodotto

• Guaina a parete media con elevate caratteristiche

di isolamento

• Guaina termorestringente per applicazioni di

superficie o sotterranee

• Protegge giunzioni e terminazioni in applicazioni a

basso voltaggio

• Rivestito internamente di adesivo termoplastico.

• Protegge dall’umidit

à e da azioni ambientali dopo

il restringimento

TERMORESTRINGENTE FINO A 4:1

GLB

Dimensioni-Dimension

1 = 12/3

2 = 22/6

3 = 33/8

4 = 40/12

5 = 55/16

MATERIALE-MATERIAL: Poliole

fina reticolata (PO-X)

Polyole

fin cross-linked

(PO-X)

Rapporto di restringimento-Shrink Ratio:

3:1

Operating Temperature :

-40 °C to +120 °C

Temp. min restringimento-Minimum Shrink Tempera-

ture:

+125 °C

Punto di fusione dell’adesivo-Softening Point Adhesive:

+85 °C

Restringimento lineare-Longitudinal change after

shrinkage:

-10 % max.

Rigidità dielettrica-Dielectric Strength:

20 kV/mm

Classe di isolamento-Insulation Class :

A (VDE 0530)

Tipo-Type

D

d

wt-spessore minimo dopo restringimento

L

colore - colour

12/3

12

3

2,2

1 mt

nero-black

22/6

22

6

2,6

1 mt

nero-black

33/8

33

8

2,6

1 mt

nero-black

40/12

40

12

2,6

1 mt

nero-black

55/16

55

16

2,7

1 mt

nero-black

MATIC · 94 · MATIC

CODIFICAZIONE
