Collettori e accessori per riscaldamento a pavimento e sanitario 06.1

Manifolds and accessories for underfloor heating and sanitary installations

Collettori in poliammide Polyamide manifolds

2303

Sistema integrato a punto fisso, per

distribuzione e regolazione bassa temperatura

composto da:

- Cassetta in lamiera verniciata

- Kit completo di circolatore elettronico Wilo

para 25/6, doppia valvola a sfera, valvola

termostatica con bulbo, valvola a tre vie e

termostato di sicurezza (max 55°C)

- Doppio by-pass

- Collettore fornito senza raccordi.

Pre-assembled unit with fixed point adjustment,

for the distribution and adjustment of low

temperature, equipped with:

- Painted metal sheet box

- Set composed of circulation pump Wilo para

25/6, double ball valve, thermostatic valve with

sensor, three way valve and safety thermostat

(max 55°C)

- Double by-pass

- Manifold supplied without connections.

2302

Sistema integrato a punto fisso, per

distribuzione e regolazione bassa temperatura

composto da:

- Cassetta in lamiera verniciata

- Kit completo di circolatore elettronico Wilo

para 25/6, doppia valvola a sfera, valvola

termostatica con bulbo, valvola a tre vie e

termostato di sicurezza (max 55°C)

- Doppio by-pass

- Collettore fornito senza raccordi.

Pre-assembled unit with fixed point adjustment,

for the distribution and adjustment of low

temperature, equipped with:

- Painted metal sheet box

- Set composed of circulation pump Wilo para

25/6, double ball valve, thermostatic valve with

sensor, three way valve and safety thermostat

(max 55°C)

- Double by-pass

- Manifold supplied without connections.

MISURA

1

1” - 2+2 VIE

1” - 3+3 VIE

1” - 4+4 VIE

1” - 5+5 VIE

1” - 6+6 VIE

1” - 7+7 VIE

1” - 8+8 VIE

1” - 9+9 VIE

1” - 10+10 VIE

1” - 11+11 VIE

1” - 12+12 VIE

1” - 13+13 VIE

2302-25000002

2302-25000003

2302-25000004

2302-25000005

2302-25000006

2302-25000007

2302-25000008

2302-25000009

2302-25000010

2302-25000011

2302-25000012

2302-25000013

1

MISURA

1”1/4 - 2+2 VIE

1”1/4 - 3+3 VIE

1”1/4 - 4+4 VIE

1”1/4 - 5+5 VIE

1”1/4 - 6+6 VIE

1”1/4 - 7+7 VIE

1”1/4 - 8+8 VIE

1”1/4 - 9+9 VIE

1”1/4 - 10+10 VIE

1”1/4 - 11+11 VIE

1”1/4 - 12+12 VIE

1”1/4 - 13+13 VIE

1”1/4 - 14+14 VIE

1”1/4 - 15+15 VIE

2303-32000002

2303-32000003

2303-32000004

2303-32000005

2303-32000006

2303-32000007

2303-32000008

2303-32000009

2303-32000010

2303-32000011

2303-32000012

2303-32000013

2303-32000014

2303-32000015

Disegni tecnici Technical drawings: page D14

Catalogo Listino Catalogue Price list 01/ 2023 S.R. Rubinetterie s.r.l.
