INNESTO DIRETTO FILETTATO FEMMINA saldatura a bicchiere
THREADED DIRECT JOINT FEMALE socket welding
Articolo
Item
65152FR
65154FR
DN /OD
F1⁄2”x50~400
F3⁄4”x50~400
SDR
5
5
A
mm
18,5
22,0
B
mm
37,0
44,0
C
mm
10,0
11,0
D
mm
47,0
49,0
F
mm
37,0
38,0
G
mm
20,0
25,0
Peso
Weight
g
33,0
44,0
pezzi
pieces
5
5
200
150
pezzi
pieces
INNESTO DIRETTO FUSIO-TECHNIK A DERIVAZIONE SAFETY saldatura a bicchiere
FUSIO-TECHNIK DIRECT JOINT WITH SAFETY DERIVATION socket welding
sm = Connessione maschio safety Connection male safety
COLLARE A SALDARE saldatura a bicchiere
COLLAR TO WELD socket welding
pezzi
pieces
Articolo
Item
65170FR
65172FR
65174FR
DN /OD
sm16x50~400
sm20x50~400
sm26x63~400
SDR
5
5
5
A
mm
18,5
18,5
22,0
B
mm
37,0
37,0
44,0
C
mm
10,0
10,0
11,0
D
mm
75,0
76,2
80,5
F
mm
37,0
37,0
38,0
G
mm
20,0
20,0
25,0
Peso
Weight
g
113,0
143,0
212,0
pezzi
pieces
5
5
5
150
Articolo
Item
65208FR
65210FR
65212FR
65214FR
65216FR
65218FR
65220FR
65222FR
65224FR
65226FR
DN /OD
20
25
32
40
50
63
75
90
110
125
SDR
11
11
11
11
11
11
11
11
11
11
B
mm
34,2
42,2
52,0
64,5
78,0
97,0
115,0
132,0
155,0
182,0
C
mm
6,2
6,7
7,5
8,7
10,0
10,0
15,0
18,0
22,0
25,0
D
mm
38,5
41,5
52,0
58,5
64,5
75,5
86,0
98,0
107,0
116,0
H
mm
30,0
32,0
40,0
45,0
48,5
56,0
63,0
71,0
75,0
80,0
G
mm
27,0
33,5
41,0
50,0
60,5
77,5
91,5
107,5
133,0
156,0
mm
28,5
34,0
41,2
50,5
63,5
81,5
93,5
110,0
136,0
166,0
I
Peso
Weight
g
13,5
22,0
37,5
56,5
73,5
135,0
246,0
379,0
556,0
1.000,0
pezzi
pieces
10
10
10
5
5
1
1
1
1
1
1000
400
300
200
100
50
40
25
16
12
pezzi
pieces
GIUNTO FILETTATO FEMMINA con sede esagonale saldatura a bicchiere
THREADED JOINT FEMALE with exagonal seat socket welding
Articolo
Item
66108FR
66109FR
66110FR
66112FR
66114FR
66116FR
66118FR
66120FR
DN /OD
F
1⁄2”-20
F3⁄4”-20
F3⁄4”-25
F1”-32
F1
1⁄4”-40
F1
1⁄2”-50
F2”-63
F2
1⁄2”-75
SDR
5
5
5
5
5
5
5
5
A
mm
19,3
22,3
22,3
29,0
37,0
39,5
46,5
58,5
B
mm
38,5
44,5
44,5
58,0
74,0
79,0
93,0
117,0
C
mm
15,0
15,0
16,0
18,5
22,5
25,5
27,5
31,5
D
mm
51,0
51,0
51,0
60,5
64,5
67,5
74,5
85,5
G
mm
33,5
33,5
39,0
43,5
53,5
72,0
85,0
100,0
H
mm
10,0
10,0
10,0
14,5
14,5
14,5
16,5
21,5
CH
mm
24,0
31,0
31,0
39,0
48,0
56,0
67,0
88,0
Peso
Weight
g
83,0
115,0
110,0
235,0
337,0
410,0
568,0
1.107,0
pezzi
pieces
10
10
10
5
5
1
1
1
200
150
150
80
50
40
25
15
pezzi
pieces
