SAE FLARE
The “C” after 1/4” indicates that the connection is suitable to
fit the access valve.
SAE FLARE UNIONS
Code
Model
Description
exag.
L mm
ØB1
ØB2
Weight
Min. Qty
05102003
3BA
Valve body
11
35
1/4”
1/4”C
22g
500
05102030
512 3BA
Valve complete with core and cap
11
35
1/4”
1/4”C
22g
500
05108026001
512 3BAK
Kit of 10 pcs. Valve complete with core and cap
11
35
1/4”
1/4”C
220 g
10
SAE FLARE X NPT UNIONS
Code
Model
Description
exag.
L mm
ØB
ØC
Weight
Min. Qty
05102004
2BA
Valve body
11
27
1/4”C
1/8”
20g
500
05102029
512 2BA
Valve complete with core and cap
11
27
1/4”C
1/8”
20g
500
05108025001
512 2BAK
Kit of 10 pcs. Valve complete with core and cap
11
27
1/4”C
1/8”
200 g
10
05102075
24F5BA
Valve body
14
27
5/16”C
1/8”
20g
500
05108108001
512 24F5BAK
Kit of 10 pcs. Valve complete with core and cap
14
27
5/16”C
1/8”
200 g
10
SAE FLARE X O.D.S. UNIONS
Ref
Code
Model
Description
exag.
L mm
ØB
ØC-ØD-ØE mm
Weight
Min. Qty
A
05102001
1BA/6,2
Valve body
11
26
1/4”C
6,2
12 g
500
A
05102002
1BA/6,4
Valve body
11
26
1/4”C
6,4 1/4”
12 g
500
B
05102005
4BA
Valve body
11
29
1/4”C
6,2-8-10
12 g
500
B
05102070
5BA
Valve body
11
29
5/16”C
6,2-8-10
13 g
500
A
05102028
512 1BA/6,2
Valve complete with core and cap
11
30.5
1/4”C
6,2
12 g
500
A
05108023001
512 1BA/6,2K
Kit of 10 pcs. Valve complete with core and cap
11
26
1/4”C
6,2
120 g
10
A
05102033
512 1BA/6,4
Valve complete with core and cap
11
26
1/4”C
6,4 1/4”
12 g
500
A
05108024001
512 1BA/6,4K
Kit of 10 pcs. Valve complete with core and cap
11
26
1/4”C
6,4 1/4”
120 g
10
B
05102031
512 4BA
Valve complete with core and cap
11
29
1/4”C
6,2-8-10
13 g
500
B
05108027001
512 4BAK
Kit of 10 pcs. Valve complete with core and cap
11
29
1/4”C
6,2-8-10
130 g
10
B
05102071
512 5BA
Valve complete with core and cap
14
30.5
5/16”C
6,2-8-10
13 g
500
B
05108089001
512 5BAK
Kit of 10 pcs. Valve complete with core and cap
14
30.5
5/16”C
6,2-8-10
130 g
10
