SUPPORTI

E PROTEZIONI

SUPPORTS AND PROTECTIONS

SUPPORTS ET PROTECTIONS

SOPORTES Y PROTECCIONES

SKU 11245

SKU 11245/B

IT

SUPPORTI REGOLABILI

UNIVERSALI

• Portata max 325 kg (sui 4 pz)

• Fonoassorbenti ed antiscivolo

• Regolabili da 9 a 14 cm di altezza con

apposita chiave (SKU 11246)

• Antivibranti grazie al distanziale in

poliuretano

• In materiale termoplastico e fibra di vetro

resistente all’usura

• Forniti in confezione da 4 pezzi

FR

SUPPORTS RÉGLABLES

UNIVERSELS

• Capacité de charge max 325 kg (pour

les 4 pièces)

• Insonorisants et antidérapants

• Réglables de 9 à 14 cm en hauteur avec

la clé appropriée (SKU 11246)

• Anti-vibration grâce à l'entretoise en

polyuréthane

• Fabriqués en matériau thermoplastique

et fibre de verre résistante à l'usure

• Fournis en paquets de 4 pièces

11245

11245/B

11246

11247

11247/B

EN

ES

UNIVERSAL ADJUSTABLE

SUPPORTS

• Max capacity 325 kg (on 4 pieces)

• Sound-absorbing and non-slip

• Adjustable from 9 to 14 cm in height

with the appropriate key (SKU 11246)

• Anti-vibration thanks to the polyuretha-

ne spacer

• Made of wear-resistant thermoplastic

and fiberglass material

• Supplied in packs of 4 pieces

SOPORTES AJUSTABLES

UNIVERSALES

• Capacidad de carga máxima 325 kg

(en 4 piezas)

• Fonoabsorbentes y antideslizantes

• Adjustables de 9 a 14 cm de altura con

la llave adecuada (SKU 11246)

• Antivibración gracias al espaciador de

poliuretano

• Hecho de material termoplástico y fibra

de vidrio resistente al desgaste

• Se suministra en paquete de 4 piezas

SKU 11246

SKU 11247

SKU 11247/B

Kit 4 x nero / black

1

Kit 4 x bianco / white

1

Chiave regolabile / Adjustable key

1

Kit 4 x base quadra/square base - nero/black

1

Kit 4 x base quadra/square base - bianco/white

1

IT

SUPPORTI A PAVIMENTO con

fissaggio vite a dado Ø 10 mm

• Realizzati in PP caricato in fibra di vetro

• Dotati di snodo e guarnizioni in NBR

• Portata massima 150 kg per kit

• Confezione da 4 pezzi

FR

SUPPORTS DE SOL

fixè avec vis et écrou Ø 10 mm

• Composè par PP renforcé fibre de verres

• Comprennent de un joint (sur la parte

supérieure) et deux NBR joints (dans la

partie inférieure)

• Capacitè max: 150 kg a kit

• Kit de 4 pcs

12200

12201

EN

GROUND SUPPORTS – fixed with

screw and nut Ø 10 mm

• Made of reinforced fiberglass-

reinforced PP

• Equipped of joint and NBR gaskets

• Max load capacity: 150 kg each kit

• Kit 4 pcs

ES

SOPORTES DE SUELO - fijación

con tornillo y tuerca Ø 10 mm

• Realizado en PP renforzado con fibra

de vidrio

• Compuesto por articolación y juntas de

caucho NBR

• Capacidad max: 150 kg en 4 piezas

• Kit de 4 un

SKU 12200

SKU 12201

Kit 4 x bianco / white / blanc / blanco

1

Kit 4 x nero / black / noir / negro

1

IT

SUPPORTI A PAVIMENTO con

perno di fissaggio a pressione

• Realizzati in PP caricato fibra di vetro

• Dotati di snodo e guarnizioni in NBR

• Portata massima 150 kg per kit

• Confezione da 4 pezzi

FR

SUPPORTS DE SOL

avec broche de fixation a pression

• Composè par PP renforcé fibre de verres

• Comprennent de un joint et deux NBR

joints

• Capacitè max: 150 kg a kit

• Kit de 4 pcs

12203

12204

SKU 12203

SKU 12204

EN

GROUND SUPPORTS

fixing pin pressure

• Made of reinforced fiberglass-

reinforced PP

• Equipped of joint and NBR gaskets.

• Max. load capacity: 150 kg each kit

• Kit 4 pcs

ES

SOPORTES DE SUELO

con pivote de fijación a presión

• Realizado en PP renforzado con fibra

de vidrio

• Compuesto de articolación y juntas de

caucho NBR

• Capacidad max: 150 kg en 4 piezas

• Kit de 4 un

Kit 4 x bianco / white / blanc / blanco

1

Kit 4 x nero / black / noir / negro

1

162

TECNOGAS

Catalogo I Catalog I Catalogue I Catálogo 2024
