PIATTELLI, GUAINE E PUNTI FISSI
COLLARI E FISSAGGI PER TUBAZIONI
DATI PER LA COMPOSIZIONE DEI COLLARI ISOLATI
Tubo
Collare
Guaina
Ø”
Ø mm
TIPO
TIPO
L mm
3/8”
12 - 18
STO/STO1 1/2”
PG4/PG4S
60
1/2”
19-23
STO/STO1 3/4”
PG4/PG4S
80
3/4”
25-28
STO/STO1 1”
PG4/PG4S
86
3/4”
26-30
STO/STO1 1 1/4”
PG8
110
1”
33-38
STO/STO1 1 1/4”
PG4/PG4S
110
1”
32-35
STO/STO1 1 1/2”
PG8
130
38-45
STP/STP1 50*
PG7/PG7S
140
1 1/4”
39-44
STO/STO1 1 1/2”
PG4/PG4S
130
1 1/2”
44-49
STO/STO1 2”
PG8
160
1” 1/2”
50-54
STP/STP1 63*
PG7/PG7S
180
52-54
STO/STO1 2”
PG4/PG4S
160
2”
60-64
STO/STO1 2 1/2”
PG7/PG7S
210
2”
63-66
STP/STP1 75*
PG7/PG7S
220
2 1/2”
73-78
STO/STO1 3”
PG7/PG7S
250
77-83
STP/STP1 90*
PG7/PG7S
270
3”
85-90
STO/STO1 3 1/2”
PG7/PG7S
280
3 1/2” 97-102
STO/STO1 4”
PG7/PG7S
320
3” 1/2” 98-102
STP/STP1 110*
PG7/PG7S
320
4”
110-116 STP/STP1 125*
PG7/PG7S
360
122-126 STP/STP1 140*
PG7/PG7S
390
125-133
STO1 5”
PG6
420
146-150 STP/STP1 160*
PG7/PG7S
460
150-159
STO1 6”
PG6
490
185-194 STP/STP1 200
PG6
600
205-210
STO1 8
PG6
660
205-210
STP1 220
PG6
660
235-244 STP/STP1 250
PG6
740
295-305 STP/STP1 315
PG6
960
385-393 STP/STP1 400
PG6
1200
3/8”
12 - 18 STO1 INOX 1/2”
PG4/PG4S
60
1/2”
19-23
STO1 INOX 3/4”
PG4/PG4S
80
3/4”
25-32
STO1 INOX1 1/4”
PG8
110
3/4”
25-30
STO1 INOX 1”
PG4/PG4S
86
1”
33-38
STO1 INOX1 1/4”
PG4/PG4S
110
1”
31-35
STO1 INOX1 1/2”
PG8
130
1 1/4”
35-42
STO1 INOX1 1/2”
PG4/PG4S
130
1 1/2”
41-47
STO1 INOX 2”
PG8
160
50-54
STO1 INOX 2”
PG4/PG4S
160
2”
59-64
STO1 INOX2 1/2”
PG7/PG7S
210
2 1/2”
73-78
STO1 INOX 3”
PG7/PG7S
250
3”
86-92
STO1 INOX3 1/2”
PG7/PG7S
280
3 1/2” 96-102
STO1 INOX 4”
PG7/PG7S
320
Tubo
Collare
Guaina
Ø”
Ø mm
TIPO
TIPO
L mm
123-130
STO1 INOX 5”
PG6
420
145-148
CTF INOX 160
PG7/PG7S
440
148-155
STO1 INOX 6”
PG6
490
156-162
CTF INOX 180
PG7/PG7S
500
185-187
CTF INOX 200
PG7/PG7S
580
PG7
PG6
PG8
PG4
PG7S
PG7S
PG7S
PG4S
PG4S
PG4S
* Senza distanziali
