MIX COM

Regola automaticamente la temperatura dell’acqua a

l

valore desiderato, indipendentemente dalle variazioni di

pressione. Assicura il massimo comfort, sensibile

economia d’acqua ed energia, evita il pericolo di scottature

accidentali. Può essere installato nei bagni e nelle docce d

i

collettività, palestre, centri sportivi

,

piscine ecc. In caso di mancata alimentazione di una delle

acque l’erogazione si ridurrà evitando così scottature

o

docce gelate. Rispettare assolutamente le connessioni

:

HOT (H) = entrata acqua calda COLD (C) = entrata acqu

a

fredda MIX = uscita acqua miscelata

It automatically regulates the water temperature at a

wished value, regardless of pressure

fluctuations. It grant

s

the maximum comfort, relevant water and

energy saving, it avoids the danger of accidental scalding.

It can be installed in community bathrooms and showers

,

gyms, sportscentres, swimming pools

,

etc. In case the cold or the hot water fails, the supply will

be reduced so to avoid scalding and cold showers.

Please keep to connections as follows:

HOT (H) = hot water inlet COLD (C) = cold water inlet

MIX = mixed water outlet

4

1

ÿ

G

1

"

6

0

2

5

5

4

1

3

8

1

3

8

G 1

"

TMTCOM100FCR

Miscelatore termostatico per impianti comunità completo di raccordi

Thermostatic mixer for community installations complete with connection

s

TMTCOM100FSR

Miscelatore termostatico per impianti comunità senza raccord

i

Thermostatic mixer for community installations without connection

s

Caratteristiche tecnich

e

- pressione max d’esercizio 10 ba

r

- n.b. per pressioni sup. a 5 bar montare un riduttore

- pressione minima 0,5 bar

- pressione raccomandata 1 ÷ 5 bar

- temperatura max acqua calda 85 °

C

- scala graduata manopola 20 ÷ 50 °

C

- pulsante di arresto a 38 °C

- connessioni 1” F - 3/4” F con valvole di ritegno e

filtri

si consiglia l’acquisto dell’art. TMTCOM100FCR comprensivo di valvole

di ritegno e

filtri sugli ingressi dell’acqua calda e fredda

Technical features

- maximum working pressure 10 ba

r

- n.b.: for pressures over 5 bar we recommend to use a reducer

- minimum pressure 0,5 bar

- recommended pressure 1 ÷ 5 bar

- hot water maximum temperature 85°

c

- temperature scaled knob 20° ÷ 50° c

- safety block 38°

c

- 1” F - 3/4” connections with check valves and

filters

we recommend the purchase art. TMTCOM100FCR that include check

valves and filters on the hot and cold water inlets.

Esempio installazione docce collettive. - Example of installation for community shower

s

PRESSIONE (bar)

0.5

1

2

3

4

5

Esempio installazione bagni pubblici. -

PRESSURE (bar)

Example of installation for public bathrooms

.

0.5

1

2

3

4

5

PORTATA (Lt/Min)

32

42

55

65

72

80

FLOW RATE (Lt/Min)

32

42

55

65

72

8

0

3

4

5

6

N. DOCCE SERVIBILI

Materiali

• corpo: ottone stampato uni en 12165 cw617n – sabbiato

• otturatore e organi interni: ottone uni en 12164 cw617

n

• manopola in hostaform/abs

• sensore a cera verne

t

7

8

N. OF USABLE SHOWERS

3

4

5

6

Material

s

• body: uni en 12165 cw617n stamped brass - sandblasted

• shutter and internal organs: uni en 12164 cw617n bras

s

• hostaform/abs handle

• vernet thermo-sensitive wax elemen

t

5

0

7
