0705
0706
Gruppo detentori interasse 50 mm per
impianti mono/bitubo con attacchi orientabili
(derivazioni a pavimento o a parete),
by-pass regolabile. Attacchi per tubo rame e
multistrato.
50 mm lockshield group for one and two pipe
systems with adjustable connections (suitable
for floor or wall connections), adjustable by-pass.
Connection for copper and multilayer tubes.
Gruppo valvola termostatizzabile e detentore
interasse 50 mm per impianti mono/bitubo
con attacchi orientabili (derivazioni a
pavimento o a parete), by-pass regolabile.
Attacchi per tubo rame e multistrato.
50 mm manual radiator valve convertible to
thermostatic and lockshield for one and two pipe
systems with adjustable connections (suitable
for floor or wall connections), adjustable by-pass.
Connection for copper and multilayer tubes.
Freestyle, Monotubo/Bitubo, 50MM 12.1
Freestyle
1/2”
3/8”
3/4” E
1/2”
3/8”
3/4” E
MISURA
3/8” x 24/19
3/8” x 3/4” E
1/2” x 24/19
1/2” x 3/4” E
3/4” E x 24/19
3/4” E x 3/4” E
NICHELATO
0705-1000N0P0
1/2”
3/8”
3/4” E
50 mm thermostatic radiator valve and
lockshield for one and two pipe systems with
adjustable connections (suitable for floor or wall
connections), adjustable by-pass.Connection for
copper and multilayer tubes.
MISURA
3/8” x 24/19
3/8” x 3/4” E
1/2” x 24/19
1/2” x 3/4” E
3/4” E x 24/19
3/4” E x 3/4” E
NICHELATO
0706-1000N0P0
0705-1000N0E0
1 20
1 20
0705-1500N0P0
0705-1500N0E0
0705-2000N0P0
0706-1000N0E0
0706-1500N0P0
0706-1500N0E0
0706-2000N0P0
0705-2000N0E0
0707
Gruppo valvola termostatica e detentore
interasse 50 mm per impianti mono/bitubo
con attacchi orientabili (derivazioni a
pavimento o a parete), by-pass regolabile.
Attacchi per tubo rame e multistrato.
0713
0707-1000N0E0
Cover 50 mm (per art. 0705, 0706, 0707).
50 mm cover (for art. 0705, 0706, 0707).
0706-2000N0E0
MISURA
3/8” x 24/19
3/8” x 3/4” E
1/2” x 24/19
1/2” x 3/4” E
3/4” E x 24/19
3/4” E x 3/4” E
0738
NICHELATO
0707-1000N0P0
1 20
N093-N094-N095
0090-0091-0815-0099
MISURA
BIANCO
-
0713-0000V00A
0490
C261
0713
1 20
0707-1500N0P0
0707-1500N0E0
0707-2000N0P0
0707-2000N0E0
3/4” E = Eurocono | Disegni tecnici Technical drawings: page D33 - D64
Catalogo Listino Catalogue Price list 01/ 2023 S.R. Rubinetterie s.r.l.
158
