TEE FILETTATO FEMMINA saldatura a bicchiere
THREADED TEE FEMALE socket welding
Articolo
Item
68008
68009
68010
68011
68014
DN /OD
20-F1⁄2”-20
20-F3⁄4”-20
25-F3⁄4”-25
25-F1⁄2”-25
32-F3⁄4”-32
SDR
5
5
5
5
5
A
mm
62,0
62,0
74,0
69,0
96,0
B
mm
29,5
29,5
34,5
34,5
43,5
C
mm
12,0
8,5
14,5
18,0
20,0
D
mm
51,8
51,8
54,3
54,3
61,3
E
mm
22,3
22,3
19,8
19,8
17,8
F
mm
31,0
31,0
37,0
34,5
48,0
G
mm
38,0
45,0
45,0
38,0
56,0
Peso
Weight
g
78,0
104,0
114,0
85,0
170,0
pezzi
pieces
10
10
10
10
5
150
100
100
100
50
pezzi
pieces
Articolo
Item
68016
DN /OD
32-F1”-32
SDR
5
A
mm
96,0
B
mm
43,5
C
mm
20,0
D
mm
75,8
E
mm
17,8
F
mm
48,0
G
mm
56,0
H
mm
14,5
CH
mm
39,0
Peso
Weight
g
283,0
pezzi
pieces
5
50
pezzi
pieces
E
TEE FILETTATO MASCHIO saldatura a bicchiere
THREADED TEE MALE socket welding
BOCCHETTONE DRITTO saldatura a bicchiere
PIPE UNION socket welding
pezzi
pieces
pezzi
pieces
pezzi
pieces
Articolo
Item
68508
DN /OD
20-M1⁄2”-20
SDR
5
A
mm
62,0
B
mm
29,5
D
mm
67,8
E
mm
22,3
F
mm
31,0
G
mm
38,0
Peso
Weight
g
110,0
pezzi
pieces
10
150
Articolo
Item
69010
69011
69012
69013
DN /OD
F3⁄4”-20
F
3⁄4”-25
F1”-25
F1”-32
SDR
5
5
5
5
A
mm
19,2
19,2
22,2
22,2
B
mm
33,5
33,5
39,0
34,5
C
mm
15,5
17,0
15,5
18,0
D
mm
41,0
41,0
41,0
41,0
G
mm
38,5
38,5
44,5
44,5
I
mm
64,5
66,0
68,0
71,5
HH
mm
14,0
14,0
16,0
16,0
CHH
mm
30,0
30,0
38,0
38,0
Peso
Weight
g
127,0
131,0
202,0
203,0
pezzi
pieces
5
5
5
5
200
150
150
100
Articolo
Item
69014
DN /OD
F1
1⁄4”-32
SDR
5
A
mm
29,0
B
mm
43,5
C
mm
18,5
D
mm
60,5
G
mm
58,0
I
mm
90,0
H
mm
14,5
CH
mm
39,0
HH
mm
20,0
CHH
mm
46,0
Peso
Weight
g
424,0
pezzi
pieces
5
50
112
