ATTACCO A SELLA saldatura a bicchiere
FUSION OUTLET socket welding
Articolo
Item
651045
651047
651046
651048
651049
Ø uscita
Ø out-put
110
110
125
125
125
per tubo
for pipe
500
560
630
400
450
500
560
630
X*
500882
500890
500898
500858
500872
500884
500892
500900
Y*
50394
50394
50394
50366-50396
50396
50396
50396
50396
A
mm
164,0
164,0
164,0
164,0
164,0
B
mm
125,0
125,0
125,0
125,0
125,0
D
mm
58,0
58,0
58,0
58,0
58,0
R
mm
425,0
425,0
425,0
425,0
425,0
Peso
Weight
g
730,9
730,9
730,9
730,9
730,9
pezzi
pieces
1
1
1
1
1
pezzi
pieces
X* Articolo matrice idonea Code
suitable weld-in-saddle
Y* Articolo fresa idonea
Code suitable miller
INNESTO DIRETTO saldatura a bicchiere
DIRECT JOINT socket welding
Articolo
Item
65132
65134
65136
65138
DN /OD
20x50~400
25x63~400
32x75~400
40x90~400
SDR
5
5
5
5
A
mm
14,8
17,3
21,8
26,8
B
mm
29,5
34,5
43,5
53,5
C
mm
10,0
11,0
12,0
14,0
D
mm
41,2
43,5
51,0
56,0
H
mm
31,2
32,5
39,0
42,0
G
mm
20,0
25,0
32,0
40,0
Peso
Weight
g
12,5
18,5
31,0
73,0
pezzi
pieces
10 1000
10 500
5
400
5
200
pezzi
pieces
INNESTO DIRETTO FILETTATO FEMMINA saldatura a bicchiere
THREADED DIRECT JOINT FEMALE socket welding
Articolo
Item
65152
65154
DN /OD
F1⁄2”x50~400
F3⁄4”x50~400
SDR
5
5
A
mm
18,5
22,0
B
mm
37,0
44,0
C
mm
10,0
11,0
D
mm
47,0
49,0
F
mm
37,0
38,0
G
mm
20,0
25,0
Peso
Weight
g
33,0
44,0
pezzi
pieces
5
200
5
150
pezzi
pieces
INNESTO DIRETTO FUSIO-TECHNIK A DERIVAZIONE SAFETY saldatura a bicchiere
FUSIO-TECHNIK DIRECT JOINT WITH SAFETY DERIVATION socket welding
sm = Connessione maschio safety Connection male safety
pezzi
pieces
Articolo
Item
65170
65172
65174
DN /OD
sm16x50~400
sm20x50~400
sm26x63~400
SDR
5
5
5
A
mm
18,5
18,5
22,0
B
mm
37,0
37,0
44,0
C
mm
10,0
10,0
11,0
D
mm
75,0
76,2
80,5
F
mm
37,0
37,0
38,0
G
mm
20,0
20,0
25,0
Peso
Weight
g
113,0
143,0
212,0
pezzi
pieces
5
150
5
5
105
