COOL-FIT 4.0 T90° ridotto
d32-d225
Modello:
•
Pre-isolato, PE100, SDR11, PN16, metrico
•
Isolamento in schiuma GF HE
•
Camicia esterna resistente agli urti. Colore: nero
•
A: Raccordo elettrosaldabile con guarnizione a labbro integrata, resistente all'umidità e alla
condensa
d
d1
D
D1DN
(mm) (mm) (mm) (mm) (mm)
Codice
738 203 218
738 203 222
738 203 223
738 203 227
738 203 228
738 203 229
738 203 240
738 203 241
738 203 242
738 203 243
738 203 447
738 203 449
738 203 450
738 203 251
738 204 251
738 203 264
738 203 266
738 203 267
738 203 268
738 204 268
738 203 269
Peso D2
L
L
1
L2
z
z1Tipo
(kg) (mm) (mm) (mm) (mm) (mm) (mm)
75 63
90 63
90 75
110 63
110 75
110 90
140 63
140 75
140 90
140 110
160 63
160 90
160 110
160 140
160 140
225 63
225 90
225 110
225 140
225 140
225 160
140 125 65
160 125 80
160 140 80
180 125 100
180 140 100
180 160 100
225 125 125
225 140 125
225 160 125
225 180 125
250 125 150
250 160 150
250 180 150
250 225 150
250 200 150
315 125 200
315 160 200
315 180 200
315 225 200
315 200 200
315 250 200
0,863 147 116 55
1,232 168 130 62
1,293 168 130 62
1,972 188 154 72
1,949 188 154 72
2,037 188 154 72
4,225 233 175 84
4,225 233 175 84
4,047 233 175 84
4,218 233 175 84
4,250 258 192 90
4,420 258 192 90
4,590 258 192 90
5,666 258 192 90
5,540 258 192 90
16,832 324 355 110
16,889 324 355 110
16,805 324 355 110
18,909 324 355 110
17,100 324 335 110
18,500 324 355 110
48 36 228,0
A
48 43 253,0
A
55 43 252,0
A
48 57 267,0
A
55 57 268,0
A
62 57 268,0
A
48 66 221,0
A
55 66 231,0
A
62 66 234,0
A
72 66 243,0
A
48 77 221,0
A
62 77 235,0
A
72 77 245,0
A
84 77 256,1
A
84 77 340,0
A
48 220 412,0
A
62 220 412,0
A
72 220 412,0
A
84 220 413,0
A
84 220 412,0
A
90 220 396,0
A
